The FG-1625R is a hardwired acoustic glassbreak detector with FlexCore processing and four selectable sensitivity levels.
What it does
It mounts on the ceiling, the same wall, an adjoining wall or the opposite wall, with a maximum range of 25 feet to the glass. It works on plate, tempered, laminated, wired, film-coated and insulating glass. A hand-clap check confirms it is working, and the FG-701 simulator can test it remotely.
Works with
Works with the Vista-20P, VISTA H3 and most 12 V hardwired panels as a zone device. No receiver is needed.
Why you want it
It covers all common glass types and adjusts to the acoustics of the room.
Specifications
| Works with panels | Any hardwired alarm panel (Vista-15P, Vista-20P, VISTA H3 and others) |
|---|---|
| Max range | 25 ft (7.6 m) to glass |
| Sensitivity | 4 levels (2 DIP switches) |
| Glass types | Plate, tempered, laminated, wired, coated, insulating |
| Processor | FlexCore ASIC |
| Test | Remote test mode with FG-701 |
| Terminals | 45 degree blocks with EOL |
